Description
SPECIFICATIONS
Length in.: 176″ (4.5)
Width in.: 99″ (2.5)
Height in.: 106″ (2.7)
Weight lbs. (kg): 5642-5842 (2559-2650)
Diameter Min in.: 31″ (.8)
Diameter Max in.: 65″ (1.7)
Bale Width in.: 47″ (1.2)
Bale Formation: 5 Belts + 3 Rollers
Types of Belts: Mato Plate
Bale Ramp: Standard
Working Width in.: 79″
Number of Tine Rows: 112
Tine Spacing in.: 2.36″
Windguard: Crop deflector
Pneumatic Gauge Wheel: Standard
Tine to Tine Pickup: 65
Flare to Flare Pickup: 79
Lift: Hydraulic
Lift Protection: Radial Clutch
Fork Feeder: Standard
Protection, Cam Clutch: Standard
Driveline Chain: 100
1 1/4″ Main Drive Chain: Standard
Wide Angle PTO Shaft: Standard
Shear Bolt Protection: Standard
Cam Clutch Protection: Standard
Binding: Net/Twine
Monitor: Focus
Twine: Double arm / N/A
ISOBUS: Optional
Focus Terminal: Standard
IsoMatch Tellus: Optional
Hydraulic Outlets: 1SA + 1DA
Wheels and Axles | 31×13.5-15: Standard
Wheels and Axles | 19.0/45-17: Optional
PTO rpm: Wide angle / 540
PTO Protection: Slip clutch
Minimum PTO Horsepower Required HP/KW: 40 – 60
