Description
SPECIFICATIONS
Engine Model: Kubota D1703M-DI-E4
Horsepower (gross): 24.8
Displacement (cu. in.): 100.5 (1647)
Overall Length: 15 ft 6 in (4730)
Overall Height: 8 ft 1 in (2480)
Overall Width: 5’1″ (1550)
Min. Ground Clearance: 11.4 (290)
Crawler Length: 6 ft 10.6 in (2100)
Pump Capacity (GPM): 10.5 (39.6) x 2 / 5.5 (20.9) x 1
Auxiliary Hydraulics Flow Rate (GPM): 15.8 (60)
Bucket Breakout Force (lbs.): 8138 (3694)
Arm Breakout Force (lbs.): 3867 (1756)
Traveling Speed: High (mph): 1.9 (3.0)
Traveling Speed: Low (mph): 2.9 (4.6)
Ground Contact Pressure (psi): Canopy rubber/steel: 4.365 (0.307) / 4.482 (0.315), Cab rubber/steel: 4.559 (0.321) / 4.676 (0.329), Angle Blade canopy rubber/steel: 4.583 (0.322) / 4.700 (0.331) Angle Blade cab rubber/steel: 4.776 (0.336) / 4.894 (0.344)
Blade Width: 5 ft 1 in (1550)
Blade Height: 1 ft 1.5 in (345), Angle Blade: 1’3.2″ (385)
Hydraulic Oil Reservoir / System: 11.8 (44.6) / 16.1 (61)
Fuel Reservoir: 12.4 (46.9)
Operating Weight lbs. (kg): Canopy rubber/steel: 7420 (3365) / 7616 (3454) Cab rubber/steel: 7742 (3511) / 7938 (3600), Angle Blade canopy rubber/steel: 7781 (3529) / 7978 (3618), Angle Blade cab rubber/steel: 8104 (3675) / 8300 (3764)
