Description
SPECIFICATIONS
Engine Model: Kubota V3307-CR-TE5
Horsepower (gross): 66.6
Displacement (cu. in.): 203.3
Overall Length: 21ft 1.9in (6450)
Overall Height: 8ft 4in (2450)
Overall Width: 7ft 2.6in (2200)
Min. Ground Clearance: 14.0in-15.4in (355-390)
Crawler Length: 9ft 6.2in (2900)
Pump Capacity (GPM): 19.0-22.3 (72.0-84.6) Variable x 2 / 17.6 (66.6) Gear x 1
Auxiliary Hydraulics Flow Rate (GPM): 26.4 (100) / 17.6 (66.6)
Bucket Breakout Force (lbs.): 14660 (6650)
Arm Breakout Force (lbs.): 8554 (3880)
Traveling Speed: High (mph): 1.7 (2.7)
Traveling Speed: Low (mph): 3.0-3.1 (4.8-5.0)
Ground Contact Pressure (psi): Rubber/steel: 5.23 (0.367) / 5.35 (0.376), Angle blade rubber/steel: 5.47 (0.385) / 5.60 (0.394)
Blade Width: 7ft 2.6in (2200)
Blade Height: 1ft 7.7in (500), Angle Blade: 1ft 8.1in (510)
Hydraulic Oil Reservoir / System: 19.8 (75) / 35.7 (135)
Fuel Reservoir: 30.4 (115)
Operating Weight lbs. (kg): Rubber/steel: 18365-18280 (8330-8290) / 18475-18390 (8380-8340), Angle blade rubber/steel: 19225-19140 (8720-8680) / 19250-19335 (8730-8770)
