Description

SPECIFICATIONS

Engine: V2607

Emission Certification: Tier 4 Final

Output (SAE J1995 gross) HP (kW)/rpm: 64.3 (48) / 2400

Output (SAE J1349 net) HP (kW)/rpm: 61.1 (45.6) / 2400

Displacement (cu. in.): 160 (2615)

Transmission Type: Hydrostatic transmission

Overall Length: 18ft. 0in. (5483)

Overall Width: 5ft. 11in. (1800)

Overall Height: 8ft 2in (2478) / 8ft 2in (2498)

Ground Clearance (in.): 13in. (330)

Auxiliary Hydraulics Flow Rate (GPM): 17.8 (67.2)

Auxiliary Hydraulic Pressure (psi): 2973 (20.5)

Standard Tire Size: 12.5-18

Traveling Speed: High (mph): 12.4 (20.0)

Traveling Speed: Low (mph): 3.0 (4.8)

Traction Force (lbs.): 8588 (38.2)

Front/Rear Axle Traction Lock: Diff-lock (both axles)

Articulation Angle (deg.): 40 (each direction)

Angle of Rear Frame Oscillation (deg.): ±8

Loader Clearance Circle ft. in. (mm): 13ft. 10in. (4221)

Turning Radius Track Circle ft. in. (mm): 12ft 0in. (3664)

Brakes (Service): Enclosed wet disc

Tipping Load (Full Turn): 6526 (2960)/6812 (3090) / 5115 (2320)/5313 (2410)

Tipping Load (Straight): 7452 (3380)/7760 (3520) / 5820 (2640)/6063 (2750)

Rated Operating Capacity (ROC): 3263 (1480)/3406 (1545) / 2558 (1160)/2657 (1205)

Standard Bucket Capacity (yd3): 0.94

Bucket Breakout Force (lbs.): 9869 (43.9)

Lifting Capacity at Ground Level lbs. (kN): 8161 (36.3)

Loader Raise / Lower Time (sec.): 5.8 / 3.9

Fuel Tank (gal.): 18.5 (70)

Hydraulic System (gal.): 15.1 (57)

Hydraulic Reservoir (gal.): 10.3 (39)

Operating Weight lbs. (kg): 11177 (5070) / 11563 (5245)

Hinge Pin Height: 10ft 8in

Dump Height at Fully Raised Position: 8ft 3in

Maximum Dump Angle: 45 degrees

Reach Fully Raised at Maximum Dump Angle: 2ft. 6in.

Steering Angle: 40 degrees

Frame Oscillation Angle: 8 degrees

$2207/MONTH

0% FINANCING FOR 48 MONTHS, 0% DOWN

MONTHLY PAYMENT INCLUDES $42 UCC FILING FEE – WITH APPROVED CREDIT

ALL SALES MUST BE MADE IN PERSON, TERMS SUBJECT TO CHANGE
