Description
SPECIFICATIONS
FarmLine: Standard
ProLine: N/A
Working Width ft. (m): 13′ 9″
Transport Width ft. (m): 6′ 7″
Transport Length ft. (m): 13′ 2″
Parking Height ft.: 7′ 7″
Weight lbs. (kg): 1257 (570)
Capacity Theo. (Acres/h): 11.4
Pivoting 3-pt Headstock (cat.): N/A
Lower Links (2-pt.): N/A
Linkage Drawbar: Standard
Gauge Wheel 16″: Optional
Rotor Diameter ft.: 11′ (3.4)
Swath Delivery: Left
Number of Rotors: 1
Number of Arms Per Rotor: 11
Number of Double Tines/Arm: 4
Tine Diameter in.: .35″
Continuous Cam Track: N/A
Detachable Tine Arms: Standard
Height Adjustment: Mechanical
Tires (Rotors): 18.5 x 8.5-8
Fixed Tandem Axle: Standard
Pivoting Tandem Axle: N/A
Stand. Tires (Carrying Frame): N/A
Carrier Arm Compensating: N/A
Locking Catch for Slopes: N/A
Warning Panels: Optional
Road Lights: Optional
