Description
SPECIFICATIONS
FarmLine: Standard
ProLine: N/A
Working Width ft. (m): 21′ 8″/23′ 3″
Transport Width ft. (m): 9′ 10″
Transport Length ft. (m): 24′ 9″
Parking Height ft.: N/A
Weight lbs. (kg): 2976
Capacity Theo. (Acres/h): 18
Pivoting 3-pt Headstock (cat.): N/A
Lower Links (2-pt.): N/A
Linkage Drawbar: Standard
Gauge Wheel 16″: Optional
Rotor Diameter ft.: 9′ 8″
Swath Delivery: Left
Number of Rotors: 2
Number of Arms Per Rotor: 11/12
Number of Double Tines/Arm: 4
Tine Diameter in.: .35″
Continuous Cam Track: N/A
Detachable Tine Arms: Standard
Height Adjustment: Hydraulic / Mechanical
Tires (Rotors): 18.5×8.5-8
Fixed Tandem Axle: Rear optional
Pivoting Tandem Axle: N/A
Stand. Tires (Carrying Frame): N/A
Carrier Arm Compensating: N/A
Locking Catch for Slopes: N/A
Warning Panels: Standard
Road Lights: Standard
