Description
SPECIFICATIONS
Horsepower (gross): 24.8
Displacement (cu. in.): 54.8 cu. in.
Engine Type: Water cooled 4 cycle diesel engine with 3 cylinder, turbo, EPA Tier 4
Rated Speed: 2800rpm
Low Idling Speed: 1250rpm
Overall Length: 107.7in.
Overall Height: 55.7in.
Rated Operating Capacity (ROC): 1000lbs. @ 35%
Tipping Load (lbs.): 2857lbs. (1296 kg)
Auxillary Hydraulic Pressure (psi): 2800
Overall Width w/ Std Bucket: 36in. (91.44)
