Description

SPECIFICATIONS

Engine: V2607-CR-TE4

Emission Certification: Tier 4

Horsepower (gross): 64.0 (47.7)

Displacement (cu. in.): 159.7 (2615)

Cylinders: 4

Bore Stroke (in.): 3.5 (87) × 4.4 (110)

Aspiration: Turbocharged

Rated Operating Capacity (ROC): 50% Tipping Load lbs.(kg): 1950 (885)

Tipping Load (lbs.): 3900 (1770)

Bucket Breakout Force (lbf.): 4839 (2195)

Lift Arm Breakout Force (lbf.): 3858 (1750)

Lift Arm Path: Vertical

Standard Tire Size: 10-16.5-8PR

Chain Size ASA#: 80

Traveling Speed: High (mph): 11.1 (17.8)

Traveling Speed: Low (mph): 6.9 (11.1)

Traction Force (lbs.): 7339 (3329)

Ground Clearance (in.): 7.6 (193)

Loader Hydraulic Flow (gpm): 18.0 (68.0)

Loader Hydraulic Pressure (psi): 3271 (230)

Auxiliary Hydraulics Flow Rate (GPM): 18.0 (68.0) / 28.0 (106.0)

Hydraulic Tank (gal.): 4.2 (16.0)

Fuel Tank (gal.): 25.4 (96.0)

Operating Weight lbs. (kg): 7099 (3220) / 7319 (3320)

Overall Height: 79.9″ (2029)

Overall Width: Width over Wheels: 66.5″ (1689), Width with Standard Bucket: 69″ (1753)

Overall Length: Without Bucket: 106.3″ (2700), With Bucket: 135.4″ (3439)

Reach at Maximum Height: 32.7″ (831)

Height to Hinge Pin: 121.5″ (3085)

$1,115/MONTH

0% FINANCING FOR 48 MONTHS, 0% DOWN

MONTHLY PAYMENT INCLUDES $42 UCC FILING FEE – WITH APPROVED CREDIT

ALL SALES MUST BE MADE IN PERSON, TERMS SUBJECT TO CHANGE
