Description
SPECIFICATIONS
Engine: V3307-CR-TE4
Emission Certification: Tier 4
Horsepower (gross): 74.3 (55.4)
Displacement (cu. in.): 203.3 (3331)
Cylinders: 4
Bore Stroke (in.): 3.8 (94) × 4.8 (120)
Aspiration: Turbocharged
Rated Operating Capacity (ROC): 50% Tipping Load lbs.(kg): 2690 (1220)
Tipping Load (lbs.): 5380 (2440)
Bucket Breakout Force (lbf.): 5884 (2669)
Lift Arm Breakout Force (lbf.): 4850 (2200)
Lift Arm Path: Vertical
Standard Tire Size: 12-16.5-10PR
Chain Size ASA#: 100
Traveling Speed: High (mph): 11.8 (19.0)
Traveling Speed: Low (mph): 7.4 (11.9)
Traction Force (lbs.): 8494 (3853)
Ground Clearance (in.): 8.1 (207)
Loader Hydraulic Flow (gpm): 20.9 (79.0)
Loader Hydraulic Pressure (psi): 3271 (230)
Auxiliary Hydraulics Flow Rate (GPM): 20.9 (79.0) / 30.4 (115.0)
Hydraulic Tank (gal.): 4.2 (16.0)
Fuel Tank (gal.): 26.9 (102.0)
Operating Weight lbs. (kg): 8245 (3740) / 8466 (3840)
Overall Height: 81.3″ (2065)
Overall Width: Width over Wheels: 71.8″ (1823), Width with Standard Bucket: 75″ (1905)
Overall Length: Without Bucket: 115.0″ (2920), With Bucket: 144.1″ (3660)
Reach at Maximum Height: 36.9″ (936)
Height to Hinge Pin: 128.3″ (3258)
$1315/MONTH
0% FINANCING FOR 48 MONTHS, 0% DOWN
