Description
SPECIFICATIONS
Horsepower (gross): 96.4
Displacement (cu. in.): 230
Overall Length: 154.6″
Overall Height: 83.3″
Overall Width: Vehicle Width: 77.2″, Width with Bucket: 80″
Operating Weight lbs. (kg): 11299 / 11574
Operator Station: Open cab / closed cab
Rated Operating Capacity (ROC): 35% Tipping Load (lbs.): 3200
Tipping Load (lbs.): 9143
Bucket Breakout Force (lbf.): 7961
Lift Arm Breakout Force (lbf.): 6742
Lift Arm Path: Vertical
Track Width (standard/wide): 17.7″
Ground Contact Pressure (psi): 4.4/4.5
Track Rollers (per side): 5
Track Ground Contact Length: 65.6″
Traveling Speed: High (mph): 7.3
Traveling Speed: Low (mph): 5
Traction Force (lbs.): 12178
Ground Clearance (in.): 11.5″
Auxiliary Hydraulic Pressure (psi): 3553
Auxiliary Hydraulics Flow Rate (GPM): 23.1/40
Height to Hinge Pin: 128.5″
Ground Pressure: 4.4/4.5
$1516/MONTH
0% FINANCING FOR 60 MONTHS, 0% DOWN
