Description
SPECIFICATIONS
Engine Model: Kubota D902-E4
Horsepower (gross): 16.1
Displacement (cu. in.): 54.8
Overall Length: 11 ft 7 in (3545)
Overall Height: 7 ft 8 in (2340)
Overall Width: 3 ft 3 in (990) / 4 ft 1 in (1240)
Min. Ground Clearance: 5.9in (150)
Crawler Length: 5 ft 2 in (1585)
Pump Capacity (GPM): 4.57 (17.3) × 2 / 2.75 (10.4) × 1
Auxiliary Hydraulics Flow Rate (GPM): 7.32 (27.7)
Bucket Breakout Force (lbs.): 3417.2 (1550)
Arm Breakout Force (lbs.): 1918 (870)
Traveling Speed: High (mph): 1.4 (2.2)
Traveling Speed: Low (mph): 2.6 (4.0)
Ground Contact Pressure (psi): 3.8 (0.27)
Blade Width: 4 ft 1 in (1240) / 3 ft 3 in (990)
Blade Height: 10.3 in (260)
Hydraulic Oil Reservoir / System: 3.4 (13) / 6.1 (23)
Fuel Reservoir: 5.02 (19)
Operating Weight lbs. (kg): 3703 (1680)
